输送机

胶带输送机

胶带输送机

【产品类别】输送机

【性能评测】★★★★★

【产品简介】胶带输送机概括 胶带输送机 也称为皮带输送机、带式输送机,主要用于煤矿、冶金、化工、电厂、码头等行业各种散料、袋装的输送,根据工艺、客户要求可以设计为水平、倾斜方式

胶带输送机特点

    宏源机械生产的胶带输送机具有输送量大、输送距离长、输送平稳,物料与输送带没有相对运动,噪音较小,结构简单、维修方便、能量消耗少、部件标准化等优点,输送带根据摩擦传动原理而运动,适用于输送堆积密度小于1.67/吨/立方米,易于掏取的粉状、粒状、小块状的低磨琢性物料及袋装物料,如煤、碎石、砂、水泥、化肥、粮食等。
    胶带输送机的带宽、机长及装配形式可根据客户要求定制,传动可用电滚筒,也可用带驱动架的驱动装置。
Characteristic
    Hongyuan Vibration production of belt conveyor are characterized by their smooth bue, long transport distance, transport, materials and conveyor belt is no relative movement, low noise, simple structure, convenient maintenance, less energy consumption, and the advantages of parts standardization, conveyor belt according to the principle of friction drive and movement, is suitable for conveying bulk density is less than 1.67 ton/cubic meters, easy to take out the powder, granular, small block of low grinding cut materials, or packaged materials, such as coal, gravel, sand, cement, chemical fertilizer, food, etc.
    The bandwidth of the belt conveyor, the captain and assembly form can be customized according to customer requirements, transmission electric drum are available, and can also be used with drive of drive device.

胶带输送机动画演示

Animation Show

    以上为某砂石生产流水线的动画演示,动画中多台皮带输送机与破碎机、振动筛等机械设备,组成一条完整的砂石生产流水线,大大提高工作效率。
     The above as a demo for a sand production line, many sets of belt conveyor in animation and crusher, vibrating screen and other mechanical equipment, form a complete sand production line, improve the work efficiency greatly.

胶带输送机使用现场

Working site
TD皮带输送机使用现场

胶带输送机技术参数

Parameter
胶带宽度 (mm) 输送长度(m) 功率(kw) 输送速度(m/s) 输送量(t/h)
500 ≤12
3
12-20
4-5.5
20-30
5.5-7.5
1.3-1.6 78-191
650 ≤12
4
12-20
5.5
20-30
7.5-11
1.3-1.6 131-323
800 ≤6
4
6-15
5.5
15-30
7.5-15
1.3-1.6 278-546
1000 ≤10
5.5
10-20
7.5-11
20-40
11-22
1.3-2.0 435-853
1200 ≤10
7.5
10-20
11
20-40
15-30
1.3-2.0 655-1284
